AUO 21.5inch Digital signage use lcd panel P215HVN02.0 1920 *1080 Pixels 102PPI 3PIN

P215HVN02.0 is a 21.5" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: Landscape / Portrait, WLED Backlight, Life ≥ 50K hours, Reverse I/F, Matte , operating max 20 hours a day. Based on its features, Einklcd recommend that this model be applied to Digital Signage etc. According to the information stored in einklcd this model mass production on Q4, 2021, Now this model is in production. We inputted this model's specification on Mar 20 2024 for the first time, and the latest update on Aug 22 2025. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail of P215HVN02.0. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand:AUO

Model P/N:P215HVN02.0
Diagonal Size:21.5"

Panel Type:a-Si TFT-LCD, LCM
Resolution:1920(RGB)×1080, FHD 102PPI

Pixel Format: RGB Vertical Stripe
Active Area 478.656(W)×260.28(H) mm

Bezel Opening 481.9(W)×263.5(H) mm
Outline Dim.: 501.88(H)×284.78(V) ×12(D) mm

TreatmentAntiglare (Haze 25%), Hard coating (3H)
Luminance: 300 cd/m² (Typ.)

Contrast Ratio: 3000:1 (Typ.) (TM)
View Direction: Symmetry

Response Time: 20 (Typ.)(G to G)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Dow

nOperating Mode: VA, Normally Black, Transmissive
Support Color: 16.7M 72% NTSC

Light Source: WLED [15S4P] , 50K hours , W/O Driver
Weight: 1.65Kgs (Typ.)

Designed For: Digital Signage
Frame Rate: 60Hz

Touch Panel: Without
Interface Type: LVDS (2 ch, 8-bit) , 30 pins Connector
Power Supply: 5.0V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ;

Storage Temperature: -20 ~ 60 °C​
